• Item Name: Agomet® F300 A with F300 B and hardener powder/paste
• Manufacturer: Huntsman Advanced Materials
• Technologies: Methacrylate adhesive, two-component, “No-mix” system
• Color: Component A – Grey/Beige, Component B – Grey/Beige, Hardener – White powder
• Cure Type: Room temperature curing
• Package Size: Contact to Techniq VN for details.
• Shelf Life: 36 months at 2–8°C (6 months at 23°C)
Agomet® F300 A with F300 B and hardener powder/paste is a two-component, room temperature curing, “No-mix” methacrylate adhesive developed by Huntsman Advanced Materials. It is specifically designed for rapid bonding applications, enabling parts to be handled within 5 minutes and reaching full strength in about 2 hours. The adhesive provides high tensile shear and peel strength, excellent thermal stability from –40°C to +130°C, and good resistance to moisture and chemicals.
Rapid production line bonding of metals and plastics.
Situations requiring fast fixture times (2–5 minutes).
Joints requiring high shear and peel strength with good durability.
Suitable for “No-mix” bead-on-bead or separate surface application.
Unmixed Components (as supplied):
| Property | F300 A | F300 B | Hardener Powder |
|---|---|---|---|
| Colour (visual) | Grey/Beige | Grey/Beige | White powder |
| Specific gravity | ~1.2 | ~1.2 | – |
| Viscosity (Pa·s) | ~15 | ~20 | – |
| Gelation time at 23°C (mixed) | – | – | ~2 minutes |
Cured Properties (typical values at 23°C unless noted):
| Property / Condition | Value / Result |
|---|---|
| Handling strength (work life / fixture time) | 2 min work-life; 5 min handling |
| Final strength | Within 2 hours |
| Tensile strength (ISO R527, cured 24h) | 26 MPa |
| Elongation at break (ISO R527) | 7.2 % |
| Lap shear strength (metal-to-metal, ISO 4587) | High (varies by metal type) |
| Lap shear strength (plastic-to-plastic, ISO 4587) | Substrate failure common |
| Roller peel test (ISO 4578) | 6 N/mm (at 23°C) |
| Glass transition temperature (Tg) | No clear transition; stable up to ~130°C |
| Coefficient of thermal expansion (–30°C to +30°C) | 70 × 10⁻⁶ /K |
| Shear modulus (DIN 53345) | 2 GPa at –40°C → 12 MPa at 120°C |
| Thermal stability | –40°C to +130°C operational |
| Chemical resistance (immersion tests) | Good resistance to water, lubricating oil, paraffin; moderate resistance to solvents like xylene, ethyl acetate |
