BERGQUIST GAP FILLER TGF 3010APS

  • Item Name: BERGQUIST GAP FILLER TGF 3010APS
  • Manufacturer: Henkel
  • Product Category: Thermal Gap Filler
  • Technologies: Silicone-free, 2-part, dispensable liquid gap filler
  • Applications: Automotive power storage, silicone-sensitive applications, high thermal transfer with low compressive stress
  • Color: Part A – Black, Part B – White, Cured – Black
  • Cure Type: Room temperature cure or heat cure
  • Package Size: Cartridges (200cc, 400cc, 1200cc), Pail Kits (6 gallons, 10 gallons), Drum Kits (120 liters)
  • Shelf Life: 3 months

1. Product Overview

BERGQUIST GAP FILLER TGF 3010APS is a silicone-free, two-part, dispensable gap filler designed for high-throughput assembly applications. It offers:

  • Thermal Conductivity: 3.0 W/m-K
  • Curing Options: Room temperature or heat cure
  • High Dispense Rate: >40 cc/sec
  • Low Compression Stress during assembly
  • Color: Part A (Black), Part B (White), Cured (Black)

2. Applications

  • Automotive power storage
  • Silicone-sensitive applications
  • High-speed dispensing processes
  • High thermal transfer with low compressive stress

3. Typical Properties

Uncured Properties

Property Part A Part B
Viscosity (mPa·s, cP) 5,000 (High Shear), 425,000 (Low Shear) 20,000 (High Shear), 650,000 (Low Shear)
Density (g/cc) 3.0 3.0
Storage Life (@ 25°C, days) 90 90
Work Life (@ 25°C, hours) 4 (Mixed)

Cure Schedule

Condition Time
Room Temperature Cure 24 hours @ 25°C
Heat Cure 3 hours @ 80°C

Cured Properties

Property Value
Hardness (Shore 00) 75
Heat Capacity (J/g-K) 0.87
Flammability UL 94 V-0
Dielectric Strength (V/mm) 14,000
Dielectric Constant (@ 1000 Hz) 17
Volume Resistivity (ohm-meter) 1×10⁶
Thermal Conductivity (W/m-K) 3.0

4. Packaging & Storage

  • Available Configurations:
    • Cartridges: 200cc, 400cc, 1200cc
    • Pail Kits: 6 gallons, 10 gallons
    • Drum Kits: 120 liters
  • Shipping Conditions: Controlled between 10ºC – 30ºC
  • Storage: Optimal at 25ºC, in sealed containers, with a 3-month shelf life
