• Item Name: DOWSIL™ CC-8036 UV and Moisture Dual Cure Conformal Coating Adhesive
• Manufacturer: Dow
• Technologies: One-part, translucent silicone conformal coating/adhesive; dual cure (UV + secondary moisture cure); stress-relieving, solvent-free
• Color: Translucent
• Cure Type: UV/LED fast cure with secondary moisture cure (tack-free 48–72 h)
• Package Size: Contact to Techniq VN for details.
• Shelf Life: Contact to Techniq VN for details.
DOWSIL™ CC-8036 UV and Moisture Dual Cure Conformal Coating Adhesive is a one-part, translucent silicone-based coating/adhesive designed for electronic protection. It cures rapidly under UV/LED light with a secondary moisture cure to ensure deep and uniform curing, even in shadowed areas. With strong dielectric performance, no added solvents, and stress-relieving characteristics, it provides reliable insulation and protection over a wide temperature range.
E-motors and automotive electronic boards
Power supplies, converters, and modules
Power tools and control units
Connectors and solder joint coverage
Home appliances
Rigid circuit boards requiring UV/LED curable protection
| Property | Unit | Still Not Mixed (One-part) | After Cured |
|---|---|---|---|
| Color | – | Translucent | Translucent |
| Non-volatile Content | % | 97 | – |
| Viscosity | cP | 60,000 | – |
| Specific Gravity | – | – | 1 |
| Durometer | Shore A | – | 30 |
| Tensile Strength | psi | – | 170 |
| Elongation | % | – | 125 |
| Dielectric Strength | kV/mm | – | 440 (non-dried) |
| Volume Resistivity | ohm·cm | – | 2.70E13 (non-dried) |
| Dielectric Constant | – | – | 2.62 (100 Hz), 2.63 (100 kHz) |
| Dissipation Factor | – | – | 0.0013 (100 Hz), <0.002 (100 kHz) |
| Certification | – | – | UL 94 V-0 (Pending) |
| Useful Temperature Range | °C | – | -40 to 150 |
LOCTITE ECCOBOND UF 9000AG-061 is specifically formulated for FCBGA and Cu pillar flip chip packaging, ensuring robust solder joint encapsulation under extreme electrothermal cycling from -65 °C to 150 °C. Its superior capillary flow also optimizes throughput in automated assembly lines for high-density ICs.
BERGQUIST microTIM mTIM 1028 is purpose built for riding cage assemblies in servers, switches, and routers, interfacing with electroless nickel plated copper or aluminum heat sinks. It ensures stable operation in high power transceiver modules while also extending applicability to liquid cooling components, heat pipes, and fin based dissipative structures.
LOCTITE® ABLESTIK NCA 3218 is specifically formulated for ADAS optical modules, ensuring secure bonding in lens barrel to housing and lens housing to circuit board interfaces where dimensional accuracy and dielectric integrity are non negotiable.
Loctite® 3296, a dual cure (UV & thermal) adhesive, is engineered for active alignment assembly of ADAS cameras and LiDAR modules. Its optimized bonding to aluminum and FR4 substrates ensures secure fixation of optical components while enabling nanometer level alignment critical for high resolution imaging.
