• Item Name: EA6107
• Manufacturer: H.B. Fuller
• Technologies: UV/moisture dual cure, acrylate-based adhesive
• Color: Blue liquid
• Cure Type: UV initiated, ambient moisture cure
• Package Size: Contact to Techniq VN for details.
• Shelf Life: 6 months
EA6107 is a UV/moisture curable adhesive designed for bonding plastics and metals. It is a no-flow, fast-cure, dual-cure system that allows curing in shadowed areas where UV light alone cannot reach. The adhesive provides rapid tack-free handling and progressively increases hardness over time through moisture curing.
Key Highlights:
Type: UV/Moisture Double-Cure Adhesive
Base: Acrylate
Appearance: Blue Liquid
Fast curing, suitable for plastics and metals
Tack-free in <15 seconds under UV
Shelf Life: 6 months (stored 2–8°C, unopened)
Bonding of plastics and metals
Suitable for shadowed areas where UV light is limited
General industrial or electronic material applications requiring fast, reliable adhesion
General Instructions:
Surfaces must be clean and free from flux, dust, or contaminants.
Use a UV lamp at 365 nm, focus on coated surfaces.
Curing speed depends on UV intensity, distance, and coating thickness.
Close container immediately after use; use a black hose for dispensing.
Store away from sunlight and artificial light sources.
Use in a well-ventilated area; follow MSDS for safety precautions.
Property | Value |
---|---|
Appearance | Blue Liquid |
Component | Acrylate |
Viscosity (25°C, CP52, 5 rpm) | 12,800 cP |
Density | 1.05 g/cm³ |
Tack-Free Time (UV) | <15 s |
Depth of Cure (30 s @ 100 mW/cm², 365 nm) | 8 mm |
Shore D Hardness (UV + Moisture Cure) | Initial: 20 1 Day: 40 3 Days: 50 5 Days: 62 7 Days: 70 |
Recommended UV Cure | 100 mW/cm² @ 365 nm, 30 s |
Moisture Cure | Ambient temperature and humidity |
Shelf Life | 6 months (2–8°C, unopened) |
