Item Name: 1527 Silicone Sealant for PV Modules
Manufacturer: H.B. Fuller
Technologies: Silicone Polymer
Color: Black
Cure Type: Moisture cure
Package Size: 310 ml, 400 ml, 600 ml, 235 kg
Shelf Life: 12 months unopened at room temperature
1527 Silicone Sealant is a high-quality, one-component adhesive based on silicone polymer that cures by reaction with moisture to form an elastic seal. It is designed for sealing the side frames of solar cells and solar energy lamps. The sealant offers excellent UV resistance, thermal performance, and durability in insulation, thermal cycling, and damp/freezing conditions. It is UL certified and provides long-lasting protection against environmental stresses.
Recommended uses include:
Sealing side frames of solar cells
Sealing solar energy lamps
General sealing and adhesive applications in photovoltaic modules exposed to heat, moisture, rain, and hail
| Property | Value |
|---|---|
| Technology / Base | Silicone |
| Components | One component |
| Curing | Moisture cure |
| Appearance / Color | Black |
| Consistency | Paste |
| Density (g/cm³) | 1.37 |
| Viscosity @ 25°C (cPs) | White paste |
| Property | Value | Test Method |
|---|---|---|
| Hardness (Shore A) | 48 | ISO7619 / GB/T531 |
| Elongation at Break (%) | 300 | ISO37 / GB/T528 |
| Tensile Strength (MPa) | 2.3 | ISO37 / GB/T528 |
| Adhesion Strength (MPa) | 1.8 | ISO4587 / GB/T1692 |
| Damp-Heat Aging Elongation at Break (%) | 320 | ISO37 / GB/T528, 85°C, 85% RH, 1000 h |
| Damp-Heat Aging Tensile Strength (MPa) | 1.6 | ISO37 / GB/T528, 85°C, 85% RH, 1000 h |
| Volume Resistivity (Ω·cm) | 1.0 × 10¹⁵ | IEC60093 |
| Breakdown Tension (kV/mm) | 20 | IEC60243-1 |
| Operating Temperature Range (°C) | -50 to 210 | – |
| Cure Depth | 2 mm @ 23±2°C, 50±5% RH, 24h | – |
