| Property | Value |
|---|---|
| Specific Gravity @ 23°C | 1.08 |
| Viscosity (mPa·s @ 25°C, 5 s⁻¹) | 19,000 |
| Property | Value |
|---|---|
| Glass Transition Temperature (Tg, °C) | 64 |
| Shore Hardness (Durometer D) | 86 |
| Water Absorption (% in boiling water) | 0.78 |
| Linear Shrinkage (%) | 2.4 |
| Volume Shrinkage (%) | 7.1 |
| Elongation at Break (%) | 3.0 |
| Tensile Strength (N/mm²) | 11 (1,600 psi) |
| Tensile Modulus (N/mm²) | 900 (130,000 psi) |
| Substrate | Bond Gap | Strength (N/mm²) | Strength (psi) |
|---|---|---|---|
| Steel (grit blasted, Activator 7387™ on 1 side, 24h @ 23°C) | 0.05 mm | 13.8 | 2,000 |
| Steel (grit blasted, Activator 7387™ on 1 side, 48h @ 23°C) | 0.127 mm | 17 | 2,500 |
| 0.25 mm | 14 | 2,000 | |
| 0.38 mm | 11 | 1,600 | |
| Steel (grit blasted, Activator 7387™ on both sides, 48h @ 23°C) | 0.127 mm | 21 | 3,000 |
| 0.25 mm | 18 | 2,700 | |
| 0.38 mm | 16 | 2,300 | |
| Ferrite Magnet to Mild Steel (Block Shear Strength, 0.05 mm gap) | – | 12 | 1,700 |
| Property | Value |
|---|---|
| 180° Peel Strength (Steel, grit blasted, N/mm) | 3.3 (19 lb/in) |
| “T” Peel Strength (Aluminum, grit blasted, N/mm) | 1.7 (10 lb/in) |
| Impact Strength (Ferrite Magnet to Mild Steel, J) | 2.3 |
