LOCTITE ABLESTIK 8700K is a non-conductive, heat-cured epoxy adhesive designed for die attach applications. It provides excellent adhesion to thin film and thick film gold surfaces and retains its dispensed height after curing without slumping. The product meets MIL-STD-883, Method 5011 requirements.
| Property | Value |
|---|---|
| Technology | Epoxy |
| Appearance | White |
| Cure Type | Heat Cure |
| Viscosity (@ 25°C) | 45,000 mPa·s (cP) |
| Work Life (@ 25°C) | 30 days |
| Shelf Life (@ -40°C) | 365 days |
| Cure Schedule | Condition |
|---|---|
| Standard Cure | 1 hour @ 175°C |
| Alternative Cure | 2 hours @ 160°C |
Physical Properties
| Property | Value |
|---|---|
| Coefficient of Thermal Expansion (CTE) | Below Tg: 20 ppm/°C Above Tg: 55 ppm/°C |
| Glass Transition Temperature (Tg) | 165°C |
| Thermal Conductivity (@ 121°C) | 0.5 W/(m-K) |
| Weight Loss (@ 300°C) | 0.35% |
| Moisture Absorption (@ 85°C/85% RH) | 1.98% |
Electrical Properties
| Property | Value |
|---|---|
| Volume Resistivity | 3 × 10¹⁴ ohm-cm |
Adhesion Properties
| Property | Condition | Value |
|---|---|---|
| Die Shear Strength | 2 × 2 mm gold substrate, @ 25°C | 30 kg-f |
BERGQUIST® GAP FILLER TGF 2900LVO, a silicone-based 2-component system, delivers optimized heat transfer across ultra-thin bondline interfaces. It is engineered for automotive control modules, high-throughput manufacturing lines, and electronics sensitive to siloxane outgassing, ensuring stable operation in environments spanning -40 °C to +150 °C.
BERGQUIST® LIQUI FORM TLF 10000 addresses critical hotspots in RRU/AAU/BBU units, EV battery packs, 5G antenna modules, industrial controllers, and compact PCBs while stabilizing vertical gaps ≤2.5 mm and preserving electrostatic reliability.
TECHNOMELT® Low Pressure Molding polyamides deliver precision encapsulation of PCBs, PCBAs, connectors, sensors, power modules, LEDs, HVAC controllers, and wearable medical devices, while also enabling leakproof integration in liquid-delivery systems.
Huntsman ARALDITE® systems are designed for • Rotor potting to replace permanent magnets in magnetless motor concepts • Stator encapsulation for enhanced coil protection • High voltage impregnation processes ensuring worker safety and long term adhesion.
