• Item Name: LOCTITE ABLESTIK ABP 2036SF
• Manufacturer: Henkel
• Technologies: Proprietary Hybrid Chemistry
• Color: Red
• Cure Type: Heat cure
• Package Size: Contact to Techniq VN for details.
• Shelf Life: 12 months
LOCTITE ABLESTIK ABP 2036SF is a red, single-component, non-conductive hybrid die attach adhesive. It is silane-free and formulated for high-throughput die attach applications, designed to minimize stress and warpage between dissimilar surfaces.
Non-conductive die attach
High-throughput manufacturing
Substrates: plastics and metals
Silane-free alternative to LOCTITE ABLESTIK 2035SC
| Property | Uncured | Cured |
|---|---|---|
| Appearance | Red | – |
| Technology | Proprietary Hybrid Chemistry | – |
| Filler Type | Silica | – |
| Viscosity, Brookfield CP51, 25°C, mPa·s (5 rpm) | 12,760 | – |
| Thixotropic Index (0.5/5 rpm) | 4.42 | – |
| Work Life @ 25°C (25% viscosity increase) | 24 h | – |
| Shelf Life @ -40°C | 365 days | – |
| Cure Schedule | 15 min @ 150°C | – |
| Alternate Cure Schedule | 90 s @ 110°C / 60 s @ 120°C / 10 s @ 150°C | – |
| Weight Loss on Cure (%) | – | 1.5 |
| Glass Transition Temperature (Tg, DMTA, °C) | – | 125 |
| DSC Onset / Peak Temperature (°C) | – | 75 / 90 |
| Thermal Conductivity (W/m·K) | – | 0.35 |
| Modulus (N/mm² / psi) | – | 25°C: 2,680 / 388,700; 150°C: 52 / 7,470; 250°C: 55 / 8,180 |
| Dielectric Strength (kV/mm) | – | 55 |
| Die Shear Strength (2×2 mm Si on PPF LF, kg/die) | – | 25°C: 12; 150°C: 1.6 |
LOCTITE ECCOBOND UF 9000AG-061 is specifically formulated for FCBGA and Cu pillar flip chip packaging, ensuring robust solder joint encapsulation under extreme electrothermal cycling from -65 °C to 150 °C. Its superior capillary flow also optimizes throughput in automated assembly lines for high-density ICs.
BERGQUIST microTIM mTIM 1028 is purpose built for riding cage assemblies in servers, switches, and routers, interfacing with electroless nickel plated copper or aluminum heat sinks. It ensures stable operation in high power transceiver modules while also extending applicability to liquid cooling components, heat pipes, and fin based dissipative structures.
LOCTITE® ABLESTIK NCA 3218 is specifically formulated for ADAS optical modules, ensuring secure bonding in lens barrel to housing and lens housing to circuit board interfaces where dimensional accuracy and dielectric integrity are non negotiable.
Loctite® 3296, a dual cure (UV & thermal) adhesive, is engineered for active alignment assembly of ADAS cameras and LiDAR modules. Its optimized bonding to aluminum and FR4 substrates ensures secure fixation of optical components while enabling nanometer level alignment critical for high resolution imaging.
