LOCTITE® EA 9480™ is a two-component, room-temperature curing epoxy adhesive designed for food contact applications. It offers good chemical resistance and is commonly used in food processing and packaging machines, as well as household appliances. This adhesive is not intended for direct food contact but may have incidental contact via the bond line.
Key Features:
| Property | Resin | Hardener | Mixture |
|---|---|---|---|
| Specific Gravity @ 25°C | 1.3 – 1.48 | 1.15 – 1.42 | – |
| Viscosity @ 25°C (mPa·s) | 7,000 – 14,000 | 3,000 – 7,500 | – |
| Pot Life (10g mix) @ 25°C | – | – | 110 – 190 min |
| Property | Value |
| Shore Hardness (ISO 868, Durometer D) | 80 |
| Coefficient of Thermal Conductivity (W/m-K) | 0.5 |
| Coefficient of Thermal Expansion (K-1) | 85 x 10^-6 (6°C – 56°C) / 200 x 10^-6 (66°C – 199°C) |
| Glass Transition Temperature (Tg) | 73°C |
| Substrate | Strength (N/mm²) | Strength (psi) |
| Mild Steel (grit blasted) | 21.0 – 27.5 | 3,045 – 3,980 |
| Stainless Steel (grit blasted) | 12.0 – 25.0 | 1,740 – 3,620 |
| Aluminum (abraded) | 11.5 – 15.5 | 1,670 – 2,250 |
| Epoxy | 6.5 – 13.0 | 940 – 1,880 |
| Polycarbonate | 3.5 – 6.2 | 500 – 870 |
| Nylon | 2.0 – 2.5 | 290 – 360 |
