LOCTITE® EA E-60HP is a two-component, toughened epoxy adhesive with medium viscosity and an extended working life. It cures at room temperature to form a strong, off-white bondline and is resistant to chemicals, solvents, and electrical insulation.
Property | Resin | Hardener | Mixed |
---|---|---|---|
Appearance | Pale yellow liquid | Yellow liquid | Off-white |
Specific Gravity (@23°C) | 1.0 | 1.0 | — |
Viscosity (Brookfield) | 67,500 mPa·s (Spindle 7, 20 rpm) | 7,000 mPa·s (Spindle 6, 50 rpm) | — |
Mix Ratio (By volume) | 2:1 | — | — |
Mix Ratio (By weight) | 100:50 | — | — |
Working Life (@23°C) | 60 minutes | — | — |
Tack-Free Time | 120 minutes | — | — |
Property | Value |
---|---|
Glass Transition Temperature (Tg) | 70°C |
Shore Hardness (Durometer D) | 80 |
Elongation at Break | 9% |
Tensile Strength | 35 N/mm² (5,100 psi) |
Dielectric Breakdown Strength | 13 kV/mm |
Substrate | Strength (N/mm²) | Strength (psi) |
---|---|---|
Mild Steel (Grit Blasted) | 30 | 4,300 |
Aluminum (Acid Etched & Abraded) | 30 | 4,300 |
Aluminum (Anodized) | 18 | 2,600 |
Stainless Steel | 27 | 3,900 |
Polycarbonate | 13 | 1,900 |
Nylon | 1.9 | 280 |
Wood (Fir) | 12 | 1,700 |
