Item Name: LOCTITE® HHD 3547BK
Manufacturer: Henkel
Technologies: Polyurethane Hot Melt
Color: Black
Cure Type: Solidification and Moisture
Package Size: Contact to Techniq VN for details.
Shelf Life: Contact to Techniq VN for details.
LOCTITE HHD 3547BK is a one-component reactive polyurethane hot-melt adhesive with 100% solids content and slight odor. It requires no mixing and cures via solidification and moisture. The adhesive provides high initial strength, is suitable for automatic or manual assembly, and is not frost sensitive, making it ideal for rapid bonding applications in structural and electronic device assembly.
Structural adhesive applications
Electronic device assembly
Automatic or manual production processes
High initial strength bonding where fast handling is required
| Property | Uncured | Cured |
|---|---|---|
| Appearance | Black | – |
| Viscosity @ 110°C, mPa·s (cP) | 5,000 | – |
| Density @ 25°C, g/cm³ | 1.1 | – |
| Open Time (1 mm bead) | ~3 min | – |
| Application Temperature (°C) | 100–110 | – |
| Elongation at Break (%) | – | 655 |
| Tensile Strength (N/mm²) | – | >8 |
| Tensile Modulus (N/mm²) | – | 130 |
| Adhesive Tensile Strength PCGF to Ink Glass | – | After 1 hr: ≥2 N/mm²; After 24 hr: ≥6 N/mm² |
LOCTITE ECCOBOND UF 9000AG-061 is specifically formulated for FCBGA and Cu pillar flip chip packaging, ensuring robust solder joint encapsulation under extreme electrothermal cycling from -65 °C to 150 °C. Its superior capillary flow also optimizes throughput in automated assembly lines for high-density ICs.
BERGQUIST microTIM mTIM 1028 is purpose built for riding cage assemblies in servers, switches, and routers, interfacing with electroless nickel plated copper or aluminum heat sinks. It ensures stable operation in high power transceiver modules while also extending applicability to liquid cooling components, heat pipes, and fin based dissipative structures.
LOCTITE® ABLESTIK NCA 3218 is specifically formulated for ADAS optical modules, ensuring secure bonding in lens barrel to housing and lens housing to circuit board interfaces where dimensional accuracy and dielectric integrity are non negotiable.
Loctite® 3296, a dual cure (UV & thermal) adhesive, is engineered for active alignment assembly of ADAS cameras and LiDAR modules. Its optimized bonding to aluminum and FR4 substrates ensures secure fixation of optical components while enabling nanometer level alignment critical for high resolution imaging.
