| Property | Value |
|---|---|
| Nominal Viscosity @ 25ºC | 250 mPa·s (cP) |
| Specific Gravity @ 25ºC | 1.08 |
| Shelf Life | 9 months (20-30ºC) |
| Curing Method | Conditions |
|---|---|
| UV Cure | 10 sec @ 300-600 mW/cm² (365 nm) |
| Moisture Cure (shadowed areas) | 2-3 days @ RT |
| Property | Value |
|---|---|
| Hardness (Shore D) | 80 |
| Thermal Conductivity @ 25°C | 0.26 W/(m-K) |
| Volume Resistivity | 3.5 × 10¹⁶ ohm-cm |
| Surface Resistivity | 3.8 × 10¹⁶ ohms |
| Dielectric Strength @ 2.64 mm | 420 volts/mil |
| Dielectric Constant @ 1MHz | 2.75 |
| Dissipation Factor @ 1MHz | 0.12 |
| Property | Value |
|---|---|
| TML (Total Mass Loss) | 0.87% |
| CVCM (Collected Volatile Condensable Material) | <0.01% |
| WVR (Water Vapor Regain) | 0.36% |
BERGQUIST® GAP FILLER TGF 2900LVO, a silicone-based 2-component system, delivers optimized heat transfer across ultra-thin bondline interfaces. It is engineered for automotive control modules, high-throughput manufacturing lines, and electronics sensitive to siloxane outgassing, ensuring stable operation in environments spanning -40 °C to +150 °C.
BERGQUIST® LIQUI FORM TLF 10000 addresses critical hotspots in RRU/AAU/BBU units, EV battery packs, 5G antenna modules, industrial controllers, and compact PCBs while stabilizing vertical gaps ≤2.5 mm and preserving electrostatic reliability.
TECHNOMELT® Low Pressure Molding polyamides deliver precision encapsulation of PCBs, PCBAs, connectors, sensors, power modules, LEDs, HVAC controllers, and wearable medical devices, while also enabling leakproof integration in liquid-delivery systems.
Huntsman ARALDITE® systems are designed for • Rotor potting to replace permanent magnets in magnetless motor concepts • Stator encapsulation for enhanced coil protection • High voltage impregnation processes ensuring worker safety and long term adhesion.
