• Item Name: Metcal STTC-125 Soldering Cartridge, Chisel 30°, 700 Series
• Manufacturer: Metcal OKI
• Primary Application: Through-hole soldering, SMD rework, standard electronic assemblies
• Compatibility: MX-500, MX-5000, MX-5200 Systems; MX-RM3E and MX-H1-AV Hand-pieces
• Tip Geometry & Size: Chisel 30°, 1.0 mm × 9.1 mm (.04″ × .33″), 700 Series, max 700°F
• Technical support: Contact to Techniq VN for details
Product Overview
The Metcal STTC-125 is a 30° chisel-tip soldering cartridge from the 700 Series, optimized for standard soldering applications. Compatible with MX-500, MX-5000, and MX-5200 Systems, as well as MX-RM3E and MX-H1-AV handpieces, it ensures precise heat delivery for through-hole and SMD rework. The tip measures 1.0 mm × 9.1 mm (0.04″ × 0.33″) and can withstand temperatures up to 700°F (371°C), offering both accuracy and reliability for fine electronic soldering tasks.
Applications
The STTC-125 is ideal for:
Through-hole soldering on standard electronic components.
Surface-mount device (SMD) rework requiring a narrow 30° chisel tip.
General soldering operations within the 700 Series specifications.
Typical Properties – Specifications
Tip Shape: Chisel 30°
Series: 700 Series
Maximum Temperature: 700°F (371°C)
Tip Dimensions: 1.0 mm × 9.1 mm (0.04″ × 0.33″)
Compatible Systems: MX-500, MX-5000, MX-5200; MX-RM3E and MX-H1-AV handpieces
