Item Name: SNAPSIL™ TSE322S
Manufacturer: Momentive Performance Materials
Technologies: One-component, heat-curable silicone adhesive sealant
Color: Light blue
Cure Type: Heat cure (100 °C – 3 h, 120 °C – 90 min, 150 °C – 60 min)
Package Size: Tubes, 333 ml cartridges, 1 kg cans, 20 kg pails
Shelf Life: Contact to Techniq VN for details.
SNAPSIL TSE322S is a one-component, heat-curable silicone adhesive sealant paste that bonds to a wide variety of substrates without the need for a primer. It features low shrinkage, non-corrosive behavior, excellent dielectric properties, and stable performance across a wide temperature range.
Adhesive and sealant for metals, plastics, rubbers, glass, and ceramics.
High-performance bonding in electronic, electrical, and industrial assemblies.
Suitable for use where primerless adhesion is required; optional primer (SS4155) can enhance adhesion on difficult substrates.
| Property | Uncured | Cured (1h @ 150°C) |
|---|---|---|
| Colour | Light Blue | – |
| Appearance | Semi-flowable | – |
| Viscosity (Pa·s, 23°C) | 70 | – |
| Density (g/cm³, 23°C) | 1.26 | – |
| Hardness (Type A) | – | 37 |
| Elongation (%) | – | 230 |
| Tensile Strength (MPa) | – | 3.6 |
| Adhesive Strength (MPa, Al lap shear) | – | 2.5 |
| Dielectric Strength (kV/mm) | – | 25 |
| Dielectric Constant (60Hz) | – | 3.1 |
| Dissipation Factor (60Hz) | – | 0.006 |
| Volume Resistivity (Ω·cm) | – | 1.0 × 10¹⁵ |
| Thermal Coefficient of Expansion (1/K) | – | 2.1 × 10⁻⁴ |
| Thermal Conductivity (W/m·K) | – | 0.29 |
LOCTITE ECCOBOND UF 9000AG-061 is specifically formulated for FCBGA and Cu pillar flip chip packaging, ensuring robust solder joint encapsulation under extreme electrothermal cycling from -65 °C to 150 °C. Its superior capillary flow also optimizes throughput in automated assembly lines for high-density ICs.
BERGQUIST microTIM mTIM 1028 is purpose built for riding cage assemblies in servers, switches, and routers, interfacing with electroless nickel plated copper or aluminum heat sinks. It ensures stable operation in high power transceiver modules while also extending applicability to liquid cooling components, heat pipes, and fin based dissipative structures.
LOCTITE® ABLESTIK NCA 3218 is specifically formulated for ADAS optical modules, ensuring secure bonding in lens barrel to housing and lens housing to circuit board interfaces where dimensional accuracy and dielectric integrity are non negotiable.
Loctite® 3296, a dual cure (UV & thermal) adhesive, is engineered for active alignment assembly of ADAS cameras and LiDAR modules. Its optimized bonding to aluminum and FR4 substrates ensures secure fixation of optical components while enabling nanometer level alignment critical for high resolution imaging.
