TEROSON® MS 9320 SF 2C is a two-component, silane-modified polymer adhesive/sealant that cures at ambient temperature. It is low viscosity, thixotropic, and free from solvents, isocyanates, and silicones.
Key Features:
✔ Very fast curing
✔ Sprayable & brushable
✔ Thixotropic after application
✔ Primerless adhesion (in most cases)
✔ Paintable up to 3 days after application
✔ Spot weldable in uncured state
✔ High UV & ageing resistance
Used in automotive E-Mobility, industrial vehicles, and repair shops for:
✔ Bonding – Floor covers, insulation panels
✔ Sealing – Low viscosity sealing applications
✔ Coating – Protective layer applications
✔ Potting – Encapsulation of components
| Property | Component A | Component B |
|---|---|---|
| Density (g/cm³) | ~1.55 | ~1.34 |
| Appearance | Grey | White |
| Property | Value | Test Standard |
|---|---|---|
| Mix Ratio (A:B by volume) | 10:1 | – |
| Pot Life | ~5-7 min | ISO 291 |
| Open Time | ~40 min | ISO 291 |
| Shore-A Hardness | ~25-30 | ISO 868 |
| Tensile Strength | ~1.4 MPa | ISO 37 |
| Elongation at Break | ~320% | ISO 37 |
| Tensile Shear Strength | ~1.2 MPa (on 1 mm Al) | EN 1465 |
| Handling Time (50% cure) | ~60-70 min | EN 1465 |
| Application Temperature | 15°C to 40°C | – |
| Service Temperature Range | -40°C to 90°C | – |
