TEROSON® MS 9320 SF 2C – Adhesive/Sealant – Automotive & E-Mobility Industry

  • Item Name: TEROSON® MS 9320 SF 2C
  • Manufacturer: Henkel
  • Technologies: Silane-modified polymer
  • Color: Component A – Grey, Component B – White
  • Cure Type: Ambient temperature
  • Package Size: Contact to Techniq VN for details.
  • Shelf Life: 12 months

1. Product Overview

TEROSON® MS 9320 SF 2C is a two-component, silane-modified polymer-based adhesive/sealant that cures at ambient temperature. It is low-viscous, thixotropic, solvent-free, and free of isocyanates and silicones. The product can be applied in beads or sprayed, offering very fast cure, high ageing resistance, UV resistance, and primerless adhesion in most cases. It is paintable up to three days after application and spot-weldable in the uncured state.

2. Applications

Designed for automotive and E-mobility industries, including:

  • Bonding: Floor covers, insulation panels
  • Sealing: Low-viscosity sealing
  • Coating & Potting applications

3. Typical Properties

Property Value
Component A Density ~1.55 g/cm³
Component B Density ~1.34 g/cm³
Mix Ratio (A:B, by volume) 10:1
Pot Life ~5–7 min
Open Time ~25 min
Shore-A Hardness (ISO 868) ~25–30
Tensile Strength (ISO 37) ~1.4 MPa
Elongation at Break (ISO 37) ~320%
Tensile Shear Strength (EN 1465, 1 mm Al) ~1.2 MPa
Handling Time (to 50%) 60–70 min
Application Temperature 15–40°C
Service Temperature -40 to 90°C
Storage Temperature 10–25°C
Shelf Life (Unopened) 12 months
