TEROSON® MS 9320 SF 2C is a two-component, silane-modified polymer-based adhesive/sealant that cures at ambient temperature. It is low-viscous, thixotropic, solvent-free, and free of isocyanates and silicones. The product can be applied in beads or sprayed, offering very fast cure, high ageing resistance, UV resistance, and primerless adhesion in most cases. It is paintable up to three days after application and spot-weldable in the uncured state.
Designed for automotive and E-mobility industries, including:
| Property | Value |
|---|---|
| Component A Density | ~1.55 g/cm³ |
| Component B Density | ~1.34 g/cm³ |
| Mix Ratio (A:B, by volume) | 10:1 |
| Pot Life | ~5–7 min |
| Open Time | ~25 min |
| Shore-A Hardness (ISO 868) | ~25–30 |
| Tensile Strength (ISO 37) | ~1.4 MPa |
| Elongation at Break (ISO 37) | ~320% |
| Tensile Shear Strength (EN 1465, 1 mm Al) | ~1.2 MPa |
| Handling Time (to 50%) | 60–70 min |
| Application Temperature | 15–40°C |
| Service Temperature | -40 to 90°C |
| Storage Temperature | 10–25°C |
| Shelf Life (Unopened) | 12 months |
LOCTITE ECCOBOND UF 9000AG-061 is specifically formulated for FCBGA and Cu pillar flip chip packaging, ensuring robust solder joint encapsulation under extreme electrothermal cycling from -65 °C to 150 °C. Its superior capillary flow also optimizes throughput in automated assembly lines for high-density ICs.
BERGQUIST microTIM mTIM 1028 is purpose built for riding cage assemblies in servers, switches, and routers, interfacing with electroless nickel plated copper or aluminum heat sinks. It ensures stable operation in high power transceiver modules while also extending applicability to liquid cooling components, heat pipes, and fin based dissipative structures.
LOCTITE® ABLESTIK NCA 3218 is specifically formulated for ADAS optical modules, ensuring secure bonding in lens barrel to housing and lens housing to circuit board interfaces where dimensional accuracy and dielectric integrity are non negotiable.
Loctite® 3296, a dual cure (UV & thermal) adhesive, is engineered for active alignment assembly of ADAS cameras and LiDAR modules. Its optimized bonding to aluminum and FR4 substrates ensures secure fixation of optical components while enabling nanometer level alignment critical for high resolution imaging.
Techniq Vietnam provides end-to-end materials and process solutions, integrating world-class technologies in adhesives, soldering, and thermal management.
Through partnerships with leading global brands, we deliver high-value materials, expert consulting, and optimized supply chains ensuring timely delivery, efficiency, and sustainable growth for our clients.
At Techniq, our mission is to connect cutting-edge materials, processes, and equipment with customer needs, enabling efficiency, reliability, and long-term value creation.
