Item Name: TEROSON® PV 3412 AA-25
Manufacturer: Henkel
Technologies: PVC Plastisol
Color: Light grey
Cure Type: Heat curing (>140°C / 15 minutes)
Package Size: Contact to Techniq VN for details.
Shelf Life: 3 months
TEROSON® PV 3412 AA-25 is a solvent-free PVC plastisol seam sealer designed for automotive applications. It cures by heat at temperatures above 140 °C for 15 minutes and demonstrates reliable paintability with common filler and topcoat systems without negative effects. The product offers strong adhesion to electro-dip coated steel substrates and maintains performance across typical automotive service conditions.
The material is used primarily as a seam sealant for butt and overlap joints in automotive body structures, applicable to both interior and exterior seams. It is applied to electro-dip steel sheets using high-pressure pumps (45:1 to 84:1 ratio), with both airless and air-mix systems, and can be adapted to robotic spray applications.
| Property | Unmixed | Mixed (if applicable) |
|---|---|---|
| Colour | Light grey | N/A |
| Density | ~1.4 g/cm³ | N/A |
| Consistency | Pasty | N/A |
| Viscosity (20 °C) | 2.5 – 3.5 Pa·s | N/A |
| Yield Point (20 °C) | 250 – 350 Pa | N/A |
| Adhesion | Good to cathodic EC substrate | N/A |
| Paintability | Compatible with filler & top coat | N/A |
| In-service Temperature Range | -30 to +80 °C | N/A |
| Storage Temp. | 15 – 25 °C | N/A |
| Shelf Life | 3 months | N/A |
This combination of rheological stability, adhesion, and paint compatibility ensures the product’s effectiveness as a durable seam sealant in automotive manufacturing.
LOCTITE ECCOBOND UF 9000AG-061 is specifically formulated for FCBGA and Cu pillar flip chip packaging, ensuring robust solder joint encapsulation under extreme electrothermal cycling from -65 °C to 150 °C. Its superior capillary flow also optimizes throughput in automated assembly lines for high-density ICs.
BERGQUIST microTIM mTIM 1028 is purpose built for riding cage assemblies in servers, switches, and routers, interfacing with electroless nickel plated copper or aluminum heat sinks. It ensures stable operation in high power transceiver modules while also extending applicability to liquid cooling components, heat pipes, and fin based dissipative structures.
LOCTITE® ABLESTIK NCA 3218 is specifically formulated for ADAS optical modules, ensuring secure bonding in lens barrel to housing and lens housing to circuit board interfaces where dimensional accuracy and dielectric integrity are non negotiable.
Loctite® 3296, a dual cure (UV & thermal) adhesive, is engineered for active alignment assembly of ADAS cameras and LiDAR modules. Its optimized bonding to aluminum and FR4 substrates ensures secure fixation of optical components while enabling nanometer level alignment critical for high resolution imaging.
